Name | Elephant SPM425 |
---|---|
Properties | OFC oxygen free copper |
Properties | Analog |
Application area | Installation |
Application area | Studio / Broadcast |
Application area | ELA 100 V |
Application | Speaker Cable |
Application | Installation cable |
Colour | black |
Colour detailed | black |
Construction | (4LIY2,5mm²)Y |
PVC | |
Jacket material | FRNC, shielded |
Jacket Ø [mm] | 8,30 |
Number of Channels (audio) | 1 |
Inner conductor (audio) | 2 |
Inner conductor (audio) [mm²] | 2,50 |
Inner conductor Ø (audio) [mm] | 1,78 |
AWG (audio) | 13 |
Copper strands (audio) | 78 |
Copper strand Ø (audio) [mm] | 0,20 |
Conductor insulation Ø [mm] | 3,05 |
Weight per 1 m [g] | 180 |
Fire load per m [kWh] | 0,8 |
Style variant | round |
Packing | 500 m spool |
Packing | bulk stock |
Temperature min. [°C] | -25 |
Temperature max. [°C] | 70 |
Width [mm] | 10,2 |
Height [mm] | 10,2 |
Insulation resist. per 1 km [GΩ] | 0,005 |
Insulation resist. per 1000 feet [GΩ] | 0,0015 |
Insulation resist. per 1 km (audio) [GΩ] | 0,005 |
Insulation resist. per 1000 feet (audio) [GΩ] | 0,0015 |
Conductor resistance per 1 km [Ω] | 7,7 |
Conductor resistance per 1000 ft. [Ω] | 2,347 |
EAN | 4049371002233 |
