Hệ thống hội nghị truyền hình 4 điểm cầu CISCO Room Kit

Phần mềm tương thích

• Cisco Collaboration Endpoint Software Version 9.0 or later, and Cisco Webex Room OS

Băng thông

• Up to 6 Mbps point-to-point

Băng thông đáp ứng/ chất lượng hình ảnh

• 720p30 from 768 kbps
• 720p60 from 1152 kbps
• 1080p30 from 1472 kbps
• 1080p60 from 2560 kbps

Mã hóa Video

• H.264, H.265

Đầu vào Video

• One HDMI input supports formats up to maximum 4K (3840 x 2160) at 30 fps including HD1080p60
• Consumer Electronics Control (CEC) 2.0

Đầu ra Video

• Two HDMI outputs support formats up to 3840 x 2160p60 (4Kp60)
• Live video resolutions (encode and decode) up to 1920 x 1080p30 and p60 (HD1080p)
• Consumer Electronics Control (CEC) 2.0

Camera tích hợp

• 5K UltraHD camera
• Supports up to 60 fps (max 30 fps with speaker tracking and best overview enabled)
• 15.1 MP image sensor (5184 x 2916 pixels)
• 1/1.7 CMOS
• 3x zoom
• f/2.0 aperture
• 83° horizontal field of view; 51.5° vertical field of view
• Auto framing (audio + face detect)
• Auto focus, brightness, and white balance
• Focus distance 1 m to infinity

Các chuẩn âm thanh

• G.711, G.722, G.722.1, G.729, AAC-LD, and Opus

Đầu vào âm thanh

• Two microphones, 4-pin mini-jack
• One audio in from HDMI
• Internal microphone

Đầu ra âm thanh

• 1 line out mini-jack (stereo)

Loa tích hợp

• High-quality speakers: five speakers in balanced configuration
• Frequency response 70 Hz to 20 kHz
• Amplifier power: 24W
• Max output level SPL 86 dB

Micro tích hợp

• 6-element microphone array for accurate speaker tracking

Tính năng luồng kép

• H.239 (H.323) dual stream
• Binary Floor Control Protocol (BFCP) (SIP) dual stream
• Supports resolutions up to 3840 x 2160p5

Chia sẻ không dây

• Cisco Webex Teams appt (up to 3840 x 2160p5)
• Cisco Intelligent Proximity client (up to 1920 x 1080p5)

Tính năng đa điểm (Yêu cầu nâng cấp)

• Adaptive SIP/H.323 MultiSite:

◦   3-way resolution up to 1080p30 + content up to 4Kp5

◦   4-way resolution up to 720p30 + content up to 4Kp5

• Full individual audio and video transcoding
• H.323/SIP/VoIP in the same conference
• Support for presentation (H.239/BFCP) from any participant at resolutions up to 3840 x 2160p5
• Best Impression (automatic continuous presence layouts)
• Encryption and dual stream from any site

Giao thức kết nối

• H.323
• SIP
• Cisco Webex

Giao thức mạng

• One Ethernet (RJ-45) 10/100/1000 for LAN
• One Ethernet (RJ-45) for Cisco Touch 10 direct pairing
• Wi-Fi 802.11a/b/g/n/ac 2.4 GHz/5 GHz, 2x2 MIMO

Cổng giao tiếp khác

• USB 2.0 port, mUSB, factory reset pinhole

Nguồn điện

• 100 to 240 VAC, 50/60 Hz, 12V DC input
• Average 20W, peak 70W
