I. Đặc điểm của micro Sennheiser EW 145-G3:
Micro Sennheiser EW 145-G3 là sản phẩm của thương hiệu Sennheiser thuộc dòng Classic Dynamic Microphone được nhập khẩu và phân phối chính hãng bởi Thiết Bị Âm Thanh Sân Khấu tại Việt Nam
Micro không dây Sennheiser EW 145 G3 được thiết kế độc đáo với 1 micro cầm tay mang phong cách riêng biệt, luôn bền bỉ với thép không dỉ, mang đến cho bạn những giây phút giải trí tuyệt vời,sóng cao tần UHF đảm bảo sóng luôn ổn định.
Pure sound: Handheld wireless system featuring the SKM100 G3 equipped with e845 super-cardioid capsule captures more of the sound you need while rejecting off-axis noise. Includes mic clip and EM100 G3 rack-mountable True Diversity receiver.
- Sturdy metal housing (transmitter and receiver
- 42 MHz bandwidth: 1680 tunable UHF frequencies for interference-free reception
- Enhanced frequency bank system with up to 12 compatible frequencies
- High-quality true diversity reception
- Pilot tone squelch for eliminating RF interference when transmitter is turned off
- Automatic frequency scan feature searches for available frequencies
- Enhanced AF frequency range
- Increased range for audio sensitivity
- Wireless synchronization of transmitters via infrared interface
- User-friendly menu operation with more control options
- Illuminated graphic display (transmitter and receiver)
- Auto-Lock function avoids accidental changing of settings
- HDX compander for crystal-clear sound
- Transmitter feature battery indicatation in 4 steps, also shown on receiver display
- Handheld transmitter with easy-exchangeable microphone modules from evolution series
- Integrated Equalizer and Soundcheck mode
- Contacts for recharging BA 2015 accupack directly in the transmitter
- Wide range of accessories adapts the system to any requirement
II. Thông số kĩ thuật micro Sennheiser EW 145-G3:
Dimensions |
Receiver: 212 x 202 x 43 mm Transmitter: Ø 50 x 265 mm |
Frequency response (Microphone) |
80 - 18000 Hz |
Compander |
HDX |
Audio-XLR connector |
6,3 mm |
Presets |
12 |
Microphone |
dynamic |
Sound pressure level (SPL) |
154 dB(SPL) max. |
THD, total harmonic distortion |
< 0,9 % |
Weight |
Receiver: 900 g Transmitter: 450 g |
AF sensitivity |
1,6 mV/Pa |
Signal-to-noise ratio |
> 110 dB(A) |
RF frequency range |
516...865 MHz |
RF output power |
30 mW |
ATransmission/receiving frequencies |
1680 |
Switching bandwidth |
42 MHz |
Peak deviation |
+/- 48 kHz |
In compliance with |
ETS 300422, ETS 300445, CE, FCC |
Operating time |
Transmitter: typ. 8 h |
Antenna connector |
2 BNC, 50 Ω |
Audio output level (balanced) |
XLR : +18 dBu max |
Audio output level (unbalanced) |
Jack : +10 dBu max |
Frequency range |
606...648 MHz 925...937.5 MHz / Korea 823...865 MHz / Power supply unit UK 823...865 MHz / Power supply unit EU / Germany 823...865 MHz / Power supply unit EU 780...822 MHz / Power supply unit UK 780...822 MHz / Power supply unit EU / Germany 780...822 MHz / Power supply unit EU 734...776 MHz / Power supply unit US 734...776 MHz / Power supply unit EU 626...668 MHz / Power supply unit US 626...668 MHz / Power supply unit EU 566...608 MHz / Power supply unit US 566...608 MHz / Power supply unit EU 516...558 MHz / Power supply unit US 516...558 MHz / Power supply unit EU |
